10 pcs - 3224G-1-202E 2kΩ, SMD Trimmer Potentiometer 0.25W Side Adjust Bourns, 3224
    • 10 pcs - 3224G-1-202E 2kΩ, SMD Trimmer Potentiometer 0.25W Side Adjust Bourns, 3224

    10 pcs - 3224G-1-202E 2kΩ, SMD Trimmer Potentiometer 0.25W Side Adjust Bourns, 3224

    10(Allparts)738014
    BOURNS
    2kΩ, SMD Trimmer Potentiometer 0.25W Side Adjust Bourns, 3224
    £40.96
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    12-Turn 250mW 4mm 3224G Series Side AdjustBourns Standard 3224G Series side adjust SMD Trimpot® trimming potentiometer with a power rating @ 70 °C of 0.25W. The 3224G series cermet trimmer features a flush adjustment screw, a pick and place centring design for automated placement compatibility and is Sealed to withstand standard board wash processing.Miniature (nominal 4mm square case size)Excellent mounting efficiencySuitable for flow/reflow soldering/hand solderMeets standard EIA and EIAJ footprintLow CRV - 1%Multi-Turn Surface Mount Trimmers
    Product Details
    BOURNS
    10(Allparts)738014
    3224G-1-202E
    10 Items

    Data sheet

    Manufacturer
    BOURNS
    Tolerance
    ±10%
    Length
    4.8mm
    Temperature coefficient
    ±100ppm/°C
    A-Supplier
    Allparts-UK/15/R-16
    Series
    3224
    Maximum Operating Temperature
    +150°C
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -65°C
    Power Rating
    0.25W
    Shaft Diameter
    1.5 mm
    Orientation
    Side Adjust
    Termination Style
    Gull Wing
    Maximum Resistance
    2kΩ
    Number of Turns
    12
