10 pcs : ZHB6790TA - TRANS 2NPN/2PNP 40V 2A SOT223
    • 10 pcs : ZHB6790TA - TRANS 2NPN/2PNP 40V 2A SOT223

    10 pcs : ZHB6790TA - TRANS 2NPN/2PNP 40V 2A SOT223

    10electronicpartsUKZHB6790TRND
    £61.00
    Delivery: 10-15 business days
    Quantity
    Last items in stock
    3 Items

    Description
    Bipolar (BJT) Transistor Array 2 NPN, 2 PNP (H-Bridge) 40V 2A 100MHz 1.25W Surface Mount SM8
    Product Details
    10electronicpartsUKZHB6790TRND
    ZHB6790TA
    3 Items

    Data sheet

    Manufacturer
    DIODES INCORPORATED
    Part status
    Active
    Series
    -
    Mounting Type
    Surface Mount
    Transistor Type
    2 NPN, 2 PNP (H-Bridge)
    Packaging
    Tape & Reel (TR)Cut Tape (CT)Digi-Reel®
    Current - Collector (Ic) (Max)
    2A
    Voltage - Collector Emitter Breakdown (Max)
    40V
    DC Current Gain (hFE) (Min) @ Ic, Vce
    200 @ 1A, 2V
    Vce Saturation (Max) @ Ib, Ic
    750mV @ 50mA, 2A
    Current - Collector Cutoff (Max)
    100nA (ICBO)
    Frequency - Transition
    100MHz
    Power - Max
    1.25W
    Supplier Device Package
    SM8
