50 pcs - SQMR715KJ TE Connectivity 15kΩ Metal Oxide Resistor 7W ±5% SQMR715KJ
    • 50 pcs - SQMR715KJ TE Connectivity 15kΩ Metal Oxide Resistor 7W ±5% SQMR715KJ

    50 pcs - SQMR715KJ TE Connectivity 15kΩ Metal Oxide Resistor 7W ±5% SQMR715KJ

    50(electronicparts)1998251P
    50 pcs - SQMR715KJ TE Connectivity 15kΩ Metal Oxide Resistor 7W ±5% SQMR715KJ
    £44.37
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    7W SQM7 SeriesTE Connectivity SQ series high power resistors featuring fine non-alkali ceramic cores embodied in ceramic cases and sealed with inorganic silica filler. This provides the SQ series with high insulation resistance, low surface temperature, excellent TCR and an entirely fireproof construction. The SQ series resistors are ideally suited to any application where efficient thermal performance is required.FlameproofPower rating of 7W at 70°CResistor marked with valueOverload Maximum 1000VWorking Voltage 500VIdeal for small batch production, development and R&D department
    Product Details
    50(electronicparts)1998251P
    SQMR715KJ
    10 Items

    Data sheet

    Manufacturer
    TE Connectivity
    Tolerance
    ±5%
    Temperature coefficient
    ±300ppm/°C
    A-Supplier
    Allparts-UK/15/R-13
    Series
    SQM7
    Maximum Operating Temperature
    +250°C
    Minimum Operating Temperature
    -55°C
    Technology
    Metal Oxide
    Lead Pitch
    5mm
