AUCTION SUBJECT:
Universal, top quality key switch with LED indicator
RS6-OL
Application: control of halogen and LED additional lighting
Parameters:
Key switch with high electrical parameters, recommended for automotive applications.
Key equipped with a red signaling LED 12V/24V DC
Electrical parameters: 30A 12VDC / 15A 24VDC)
Mounting hole: 12.2 mm
Outer flange: 30x19 mm
Height above the mounting panel: 10-17 mm
Depth with contacts: 28 mm
Thickness of the mounting panel: 4.0 mm max
Connections: copper connectors 6.3 x 0.8 mm
