    100 pcs - VLS5045EX-101M-H TDK, VLS-EX-H, 5045 Shielded Wire-wound SMD Inductor with a Ferrite Core, 100 μH ±20% Shielded 800mA
    • 100 pcs - VLS5045EX-101M-H TDK, VLS-EX-H, 5045 Shielded Wire-wound SMD Inductor with a Ferrite Core, 100 μH ±20% Shielded 800mA

    100 pcs - VLS5045EX-101M-H TDK, VLS-EX-H, 5045 Shielded Wire-wound SMD Inductor with a Ferrite Core, 100 μH ±20% Shielded 800mA

    100(electronicparts)2119534
    TDK
    100 pcs - VLS5045EX-101M-H TDK, VLS-EX-H, 5045 Shielded Wire-wound SMD Inductor with a Ferrite Core, 100 μH ±20% Shielded 800mA Idc
    £62.00
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The TDK VLS-EX-H series magnetic shield wire wound ferrite core surface mount inductor has inductance rating 100μH ±20% at 100kHz. It is used for automotive-related equipment like ECM, airbags, headlights, electronic power steering, meters, ABS, etc.Magnetic shield type wound inductor for power circuitsHigh magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mountingLarger current and lower Rdc were achieved by optimizing the ferrite core figure
    Product Details
    TDK
    100(electronicparts)2119534
    VLS5045EX-101M-H
    10 Items

    Data sheet

    Manufacturer
    TDK
    Tolerance
    ±20%
    Dimensions
    5.0 x 5.3 x 4.5mm
    Height
    4.5mm
    Length
    5mm
    Depth
    5.3mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    VLS-EX-H
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    800mA
    Inductance
    100 μH
    Package/Case
    5045
    Automotive Standard
    AEC-Q200
    Maximum DC Resistance
    754mΩ
    Core Material
    Ferrite
    Inductor Construction
    Shielded
