    50 pcs - VLS6045EX-220M-H TDK, VLS-EX-H, 6045 Shielded Wire-wound SMD Inductor with a Ferrite Core Core, 22 μH ±20% Shielded 2.4
    • 50 pcs - VLS6045EX-220M-H TDK, VLS-EX-H, 6045 Shielded Wire-wound SMD Inductor with a Ferrite Core Core, 22 μH ±20% Shielded 2.4

    50 pcs - VLS6045EX-220M-H TDK, VLS-EX-H, 6045 Shielded Wire-wound SMD Inductor with a Ferrite Core Core, 22 μH ±20% Shielded 2.4

    50(electronicparts)2138202
    TDK
    50 pcs - VLS6045EX-220M-H TDK, VLS-EX-H, 6045 Shielded Wire-wound SMD Inductor with a Ferrite Core Core, 22 μH ±20% Shielded 2.4A Idc
    £51.86
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The TDK VLS-EX-H series Ferrite core Magnetic Shield Wire Wound, 22uH SMD inductor.Magnetic shield type wound inductor for power circuits.High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting.Larger current and lower Rdc were achieved by optimizing the ferrite core figure.Compliant with AEC-Q200
    Product Details
    TDK
    50(electronicparts)2138202
    VLS6045EX-220M-H
    10 Items

    Data sheet

    Manufacturer
    TDK
    Tolerance
    ±20%
    Dimensions
    6.0 x 6.3 x 4.5mm
    Height
    4.5mm
    Length
    6mm
    Depth
    6.3mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    VLS-EX-H
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    2.4A
    Inductance
    22 μH
    Package/Case
    6045
    Automotive Standard
    AEC-Q200
    Maximum DC Resistance
    137mΩ
    Core Material
    Ferrite Core
    Inductor Construction
    Shielded
