50 pcs - IHLP2020CZER100M11 Vishay, IHLP-2020CZ-11, 2020 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20
    • 50 pcs - IHLP2020CZER100M11 Vishay, IHLP-2020CZ-11, 2020 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20

    50 pcs - IHLP2020CZER100M11 Vishay, IHLP-2020CZ-11, 2020 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20

    50(electronicparts)7486962
    VISHAY
    50 pcs - IHLP2020CZER100M11 Vishay, IHLP-2020CZ-11, 2020 Shielded Wire-wound SMD Inductor with a Metal Composite Core, 10 μH ±20% Shielded 2.75A Idc
    £47.78
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    IHLP2020CZ-11 Series Magnetically Shielded Wire Wound ChokesVishay IHLP-2020CZ-11 series high current low profile shielded inductors. The IHLP-2020CZ-11 series handles high transient current spikes without saturation and has ultra low buzz noise due to its composite construction.Frequency range up to 1.0 MHzLowest DC Resistance / μH, in this package sizeApplications include: PDA/notebook/desktop/server devices, High current POL converters, Low profile, high current power supplies, Battery powered devices, DC/DC converters in distributed power systems, DC/DC converter for Field Programmable Gate Array (FPGA)Vishay Non Standard SMT Inductors (Chokes)
    Product Details
    VISHAY
    50(electronicparts)7486962
    IHLP2020CZER100M11
    10 Items

    Data sheet

    Manufacturer
    VISHAY
    Tolerance
    ±20%
    Dimensions
    5.49 x 5.18 x 3mm
    Height
    3mm
    Length
    5.49mm
    Depth
    5.18mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    IHLP-2020CZ-11
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -55°C
    Shielded
    Yes
    Maximum DC Current
    2.75A
    Inductance
    10 μH
    Package/Case
    2020
    Maximum DC Resistance
    131.9mΩ
    Core Material
    Metal Composite
    Inductor Construction
    Shielded
    Maximum Self Resonant Frequency
    17MHz
    Moulded
    Yes
