10 pcs - 7447789222 Wurth, WE-PD, 7332 Shielded Wire-wound SMD Inductor 220 μH ±20% Wire-Wound 430mA Idc
    • 10 pcs - 7447789222 Wurth, WE-PD, 7332 Shielded Wire-wound SMD Inductor 220 μH ±20% Wire-Wound 430mA Idc

    10 pcs - 7447789222 Wurth, WE-PD, 7332 Shielded Wire-wound SMD Inductor 220 μH ±20% Wire-Wound 430mA Idc

    10(electronicparts)7981644
    10 pcs - 7447789222 Wurth, WE-PD, 7332 Shielded Wire-wound SMD Inductor 220 μH ±20% Wire-Wound 430mA Idc
    £49.26
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    WE-PD Series Magnetically Shielded Wire Wound ChokesWurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recommended solder profile: Reflow. Operating temperature -40 to +125°C.ApplicationsSwitching regulators with low operating voltagesIntegrated DC-DC convertersSwitching regulators with high efficiency (>,86%)Graphic cardsNotePlastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction.Wurth Non Standard SMT Inductors (Chokes)
    Product Details
    10(electronicparts)7981644
    7447789222
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Tolerance
    ±20%
    Dimensions
    7.3 x 7.3 x 3.2mm
    Height
    3.2mm
    Length
    7.3mm
    Depth
    7.3mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    WE-PD
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    430mA
    Inductance
    220 μH
    Package/Case
    7332
    Maximum DC Resistance
    1.65Ω
    Inductor Construction
    Wire-Wound
    Maximum Self Resonant Frequency
    5.6MHz
    Moulded
    Yes
