10 pcs - 744771115 Wurth, WE-PD, 1260 Shielded Wire-wound SMD Inductor 15 μH ±20% Wire-Wound 3.75A Idc
    • 10 pcs - 744771115 Wurth, WE-PD, 1260 Shielded Wire-wound SMD Inductor 15 μH ±20% Wire-Wound 3.75A Idc

    10 pcs - 744771115 Wurth, WE-PD, 1260 Shielded Wire-wound SMD Inductor 15 μH ±20% Wire-Wound 3.75A Idc

    10(electronicparts)7896823
    10 pcs - 744771115 Wurth, WE-PD, 1260 Shielded Wire-wound SMD Inductor 15 μH ±20% Wire-Wound 3.75A Idc
    £56.46
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    SMD Power Inductors Type WE-PD (Metal Base 1260 - 1210)Magnetically shielded version which results in a low leakage fieldHigh storage capacityLow self-lossesHighest possible current loading for SMD InductorsOperating temperature -40 to +125°CRecommended solder profile: ReflowApplications: Switching regulators with low operating voltages, Integrated DC/DC-converter, Perfectly suitable for switching regulators with extremely high efficiency (>,86%), Graphic cards
    Product Details
    10(electronicparts)7896823
    744771115
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Tolerance
    ±20%
    Dimensions
    12 x 12 x 6mm
    Height
    6mm
    Length
    12mm
    Depth
    12mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    WE-PD
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    3.75A
    Inductance
    15 μH
    Package/Case
    1260
    Maximum DC Resistance
    30mΩ
    Inductor Construction
    Wire-Wound
    Maximum Self Resonant Frequency
    16.6MHz
