10 pcs - 7447785006 Wurth, WE-PD, 6033 Shielded Wire-wound SMD Inductor 6.8 μH ±25% 2.3A Idc
    • 10 pcs - 7447785006 Wurth, WE-PD, 6033 Shielded Wire-wound SMD Inductor 6.8 μH ±25% 2.3A Idc

    10 pcs - 7447785006 Wurth, WE-PD, 6033 Shielded Wire-wound SMD Inductor 6.8 μH ±25% 2.3A Idc

    10(electronicparts)7981559
    10 pcs - 7447785006 Wurth, WE-PD, 6033 Shielded Wire-wound SMD Inductor 6.8 μH ±25% 2.3A Idc
    £35.92
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    WE-PD Series Magnetically Shielded Wire Wound ChokesWurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recommended solder profile: Reflow. Operating temperature -40 to +125°C.ApplicationsSwitching regulators with low operating voltagesIntegrated DC-DC convertersSwitching regulators with high efficiency (>,86%)Graphic cardsNotePlastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction.Wurth Non Standard SMT Inductors (Chokes)
    Product Details
    10(electronicparts)7981559
    7447785006
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Tolerance
    ±25%
    Dimensions
    5.9 x 6.2 x 3.3mm
    Height
    3.3mm
    Length
    5.9mm
    Depth
    6.2mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    WE-PD
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    2.3A
    Inductance
    6.8 μH
    Package/Case
    6033
    Maximum DC Resistance
    100mΩ
    Maximum Self Resonant Frequency
    45MHz
    Moulded
    Yes
