10 pcs - 7447785122 Wurth, 6033 Shielded Wire-wound SMD Inductor 22 μH ±25% Wire-Wound 1.35A Idc
    • 10 pcs - 7447785122 Wurth, 6033 Shielded Wire-wound SMD Inductor 22 μH ±25% Wire-Wound 1.35A Idc

    10 pcs - 7447785122 Wurth, 6033 Shielded Wire-wound SMD Inductor 22 μH ±25% Wire-Wound 1.35A Idc

    10(electronicparts)7981561P
    10 pcs - 7447785122 Wurth, 6033 Shielded Wire-wound SMD Inductor 22 μH ±25% Wire-Wound 1.35A Idc
    £35.60
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    WE-PD Series Magnetically Shielded Wire Wound ChokesWurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recommended solder profile: Reflow. Operating temperature -40 to +125°C.ApplicationsSwitching regulators with low operating voltagesIntegrated DC-DC convertersSwitching regulators with high efficiency (>,86%)Graphic cardsNotePlastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction.Wurth Non Standard SMT Inductors (Chokes)
    Product Details
    10(electronicparts)7981561P
    7447785122
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Tolerance
    ±25%
    Dimensions
    5.9 x 6.2 x 3.3mm
    Height
    3.3mm
    Length
    5.9mm
    Depth
    6.2mm
    A-Supplier
    Allparts-UK/15/R-13
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    1.35A
    Inductance
    22 μH
    Package/Case
    6033
    Maximum DC Resistance
    250mΩ
    Inductor Construction
    Wire-Wound
    Maximum Self Resonant Frequency
    23MHz
    Moulded
    Yes
