10 pcs - 74477830 Wurth, WE-PD Shielded Wire-wound SMD Inductor with a Ferrite Core, 1 mH ±20% Wire-Wound 200mA Idc
    • 10 pcs - 74477830 Wurth, WE-PD Shielded Wire-wound SMD Inductor with a Ferrite Core, 1 mH ±20% Wire-Wound 200mA Idc

    10 pcs - 74477830 Wurth, WE-PD Shielded Wire-wound SMD Inductor with a Ferrite Core, 1 mH ±20% Wire-Wound 200mA Idc

    10(electronicparts)6171524
    10 pcs - 74477830 Wurth, WE-PD Shielded Wire-wound SMD Inductor with a Ferrite Core, 1 mH ±20% Wire-Wound 200mA Idc
    £32.40
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    WE-PD Series Magnetically Shielded Wire Wound ChokesWurth WE-PD wirewound surface mount inductor is magnetically shielded resulting in a low leakage field. These power inductors have high storage capacity and high current loading. Recommended solder profile: Reflow. Operating temperature -40 to +125°C.ApplicationsSwitching regulators with low operating voltagesIntegrated DC-DC convertersSwitching regulators with high efficiency (>,86%)Graphic cardsNotePlastic base variant applications are particularly suited to high vibration or shock applications due to its one piece construction.Wurth Non Standard SMT Inductors (Chokes)
    Product Details
    10(electronicparts)6171524
    74477830
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Tolerance
    ±20%
    Dimensions
    7.3 x 7.3 x 3.2mm
    Height
    3.2mm
    Length
    7.3mm
    Depth
    7.3mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    WE-PD
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -40°C
    Shielded
    Yes
    Maximum DC Current
    200mA
    Inductance
    1 mH
    Maximum DC Resistance
    9.44Ω
    Core Material
    Ferrite
    Inductor Construction
    Wire-Wound
    Maximum Self Resonant Frequency
    2MHz
