Stucchi hydraulic quick connector 3 4 firg 34

THE OFFER APPLIES TO THE STUCCHI 3/4' FIRG 34 PLUG QUICK DRY CUTTING CONNECTOR Since 1960, Stucchi has been a leading manufacturer of quick connectors, multi-connectors and quick connection solutions. It has branches all over the world (USA, China, Australia, Brazil). Maintains a commitment to safe, reliable, high-quality products.

FIRG Series

"FIRG" is an original series of flat connectors. Designed in 1983, the "FIRG" series immediately became a major innovation in the field of quick connectors. Used in many hydraulic sectors, over time it has become a leading series in the implementation of the international standard ISO 16028 regarding the interchangeability of clutches. Thanks to its good performance and the many advantages it offers, even today the "FIRG" series is widely used and recognized by the world's largest manufacturers of hydraulic machinery and equipment. It is used in all applications where it is necessary to eliminate fluid loss and contamination of the system.

- Interchange ISO 16028

- Type Flat Face

- Pressure connection not allowed

- Material / Processing Carbon steel, Cr3

- Push connection system

- Nitrile NBR seal

- Available sizes From 1/4" to 2" (please visit other auctions)

- operating pressure in the case of 3/4' included up to 250 bar (rupture 1000 bar) Plug up to 250 bar (rupture 1000 bar) Socket up to 100 bar (burst 400 bar)

- Locking mechanism, locking ball, safety lock

- Temperature -20°C / +100°C

- Flow suggested up to 90l/min at 3/4'

- BSP, NPT threads available , SAE

Benefits of FLAT-FACE flat quick connectors

Easy to clean flat front surfaces, prevents dirt from entering during coupling, reducing the likelihood of dirt entering the system.

Minimum loss of fluid during coupling with full respect for the environment.

Reducing the likelihood of air entry during coupling/uncoupling.

The special internal design guarantees maximum resistance and minimum load losses, which leads to energy savings of the entire system.

The modular design allows for a wide range of threads without the need for adapters.

Good resistance to pulsating pressures.

Compact dimensions

Security and ease of use.

Due to the continuous operation of the quick connectors, WE RECOMMEND REPLACING THE SET, i.e. PLUG and SOCKET. This significantly reduces the risk of leakage and wear.

We also offer quick connectors in other sizes and types.
