    1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control
    • 1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control
    • 1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control
    • 1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control
    • 1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control

    1 pcs - Schneider Electric SSL Series Solid State Relay, 0.1 A Load, PCB Mount, 48 V dc Load, 12 V dc Control

    Allparts-UK/15/R/922-1852
    £37.44
    Delivery: 4-7 business days
    Quantity
    34 Items

    Product Details
    SCHNEIDER ELECTRIC
    Allparts-UK/15/R/922-1852
    SSL1D101JD
    34 Items

    Data sheet

    Manufacturer
    SCHNEIDER ELECTRIC
    Capacitance
    1.5pF
    Dimensions
    28 x 5 x 15mm
    Height
    15mm
    Length
    28mm
    Range
    Harmony Solid State Relays
    Depth
    5mm
    Number of poles
    1
    A-Supplier
    Allparts-UK-R
    Series
    SSL
    Better World Product
    Yes
    Better World Verification
    Green Premium
    Terminal Type
    PCB Pin
    Maximum Operating Temperature
    +80°C
    Mounting Type
    PCB Mount
    Minimum Operating Temperature
    -20°C
    Standards Met
    CE, CSA, UL
    Contact Configuration
    SPST
    Special Features
    Built-In Diode Protection Circuit & LED Indicator, Mounted on Universal AC/DC Sockets, Slim Interface SSL Relays with PCB Terminals
    Operating Temperature Range
    -20 - +80°C
    Maximum Load Current
    0.1 A
    Maximum Load Voltage
    48 V dc
    Minimum Load Voltage
    1 V dc
    Switching Type
    DC
    Minimum Load Current
    0.001 A
    Output Device
    MOSFET
    Maximum Control Voltage
    12 V dc
    Minimum Control Voltage
    3 V dc
    Control Voltage Range
    3 - 12 V dc
    Load Voltage Range
    1 - 48V dc
    Off State Leakage Current
    0.001 mA
    Maximum Turn On Time
    0.02ms
    Relay Type
    Single Phase
