Cyrix-Li-ct 12/24-230 lead-acid battery connector with LiFePO4

The functionality of Cyrix-Li-ct is analogous to Cyrix-ct. Cyrix-Li-ct will connect a lead-acid battery and a LiFePO4 battery in parallel:

- if the Charge Disconnect output of the VE.Bus BMS is high, and

- if it detects 13.4V (resp. 26.8V) or more on one of its power terminals. Cyrix will immediately disconnect:

- when its control output becomes free-floating, indicating cell overvoltage or cell overheating and/or

- when the battery voltage drops below 13.2V.

Start assist function: a short negative pulse will close the relay for 30 seconds.

The Cyrix-li-ct device is controlled directly from the battery management system, e.g. VE.Bus BMS or smallBMS, by providing a high and low signal. It does not require the use of a reverse connection cable as in the case of remote output.

Parameters / Model Cyrix-Li-ct 12/24-230

Direct current 230A

Controlled by SmallBMS and VE.Bus BMS

Connection voltage

13.4V <, V <, 13.7V: 120 s

13.7V <, V <, 13.9V: 30 s

V >, 13.9V: 4 s

Disconnect voltage 13.3V <, V <, 13.2V: 10 s / V <, 13.2V: immediately

Current consumption in the open state <.4 mA

Start Assist yes

Protection category IP54

Weight 0.11 kg

Dimensions 46 x 46 x 80 mm
