Inverter off grid hybrid solar 10 2kw 48v 2x MPPT anern

WARNING: Do-it-yourself installation may result in danger or damage to the equipment. Commissioning should be performed by an electrician with experience in operating these devices, according to the following rules:

The nominal power of the inverter and PV installation should be three times higher than the power of the connected energy receivers. If the starting power of the connected loads exceeds the power of the inverter, it may be damaged. Please select the appropriate inverter model before purchasing.

Connect the power circuits correctly according to the instructions and install breakers and protection devices for each circuit.

Initial start-up: turn on the breaker first battery, turn on the inverter and turn on the PV, grid and load switches.

Shutdown: turn off the loads, PV and grid, turn off the inverter, and finally turn off the battery.

New, unused, hybrid inverters 10.2kW, 230V solar inverters off-grid 48V, with WIFI Anern EX-PRO 10200

They work with or without a battery. NOTE: without batteries, the voltage of the solar panel must exceed 360 VDC.

WiFi module included

Inverter features:

On/off grid inverter. (currently in Poland it only works off grid, no certificates for ZE)

Can operate without a battery.

Has 2 separate MPPTs, 2x18A

Possibility of restoring to factory settings.

Built-in automatic activation of the lithium battery.

Intelligent battery charging to extend its service life.

Dual AC output.

WIFI available for IOS and Android.

Note:

You must properly match the battery capacity to the system according to the specific power consumption requirements. Too small will lead to a rapid decline in battery capacity. Too much energy to waste.

Dual output function description:

The main and auxiliary outputs are used under normal operating conditions. But under the following two conditions, the main output is disconnected and only the auxiliary output is retained:

When there is no solar power consumption and no grid power supply,

When the battery voltage is lower than 44V (the minimum can be set to 41V and the maximum can be set to 46V)

Advantages of dual AC output:

In the system using lithium batteries to store energy, when the inverter is under full or heavy load, due to the characteristics of lithium batteries, the battery voltage tends to drop too quickly, This causes the battery voltage to be too low and disconnects the battery while the battery still maintains 50% of the rated power.

With the dual output function, the user can connect several important loads to the secondary output. When the battery voltage is low (usually lower than 44V, with the minimum setting of 41V), the inverter needs to disconnect the main load and provide secondary load output, which will extend the running time.

Parameters:

Model: EVO-10200

Rated power: 10200W

Maximum PV input power: 5400W + 5400W

PV input (DC)

DC voltage from PV: nominal/maximum DC voltage 360VDC/500VDC

Starting voltage/initial supply voltage: 90VDC/120VDC

DC voltage range MPPT: 90-450VDC

Number of MPPT trackers/maximum input current: 1/27A or 2x 18A

Network output (AC)

Nominal AC output voltage: 220/230/240VAC

AC output voltage range: 195.5- 253VAC

Nominal AC output current: 44A

Power factor: >,0.99

Main network frequency range: 49-51 ± 1Hz / 59-61 ± 1Hz

Efficiency

Maximum conversion efficiency (PV to AC): 98 %

Two load outputs

Full load: 10200W

Main output load: 10200W

Auxiliary output maximum load (battery mode): 3400W

Main load cut-off voltage: 52VDC

Main load return voltage: 54VDC

Off grid operation

AC start voltage/auto restart voltage: 120-140VAC/180VAC

Allowable AC input voltage range: 90-280VAC or 170-280VAC

Maximum AC input current: 50A

Nominal operating frequency: 50/ 60Hz

Surge power: 12400W

Battery mode output (AC)

Nominal output voltage: 220/230/240VAC

Output waveform: Pure sine wave

Efficiency (DC to AC): 94%

Battery and charging

Nominal DC voltage: 48VDC

Maximum charging current (Solar to AC): 180A

General

Dimensions: 450*350*110mm

Net weight: 10kg

Communication interface: WIFI (module included)

Operating humidity: 5% to 95% RH (non-condensing)

Operating temperature: -10° to +50°C

Storage temperature: -15° to +60°C

Frequently asked questions:

Q: do you need to connect batteries?

A: no

Q: can you connect the power supply from the inverter directly to the receivers?

A: yes

Q: can it be connected to the grid?

A: no, there are no certificates in Poland for ZE

Q: how many solar panels need to be connected?

A: to start the inverter normally, the voltage of the solar panels should be 300V-400V, the maximum should not exceed 500V. For example, 10 pieces of 250W 30V solar panels are connected in series.

Q: Can the inverters be connected in series or parallel?

A: No.

Q: Does the inverter need to be connected to the battery?

A: Can be connected . If it is not, the solar panel voltage should be above 360vdc.

Q: What kinds of batteries can be used?

A: Lead-acid batteries, gel batteries, lithium iron phosphate (LiFePo4) and lithium batteries can be used. 24V. The battery cannot be less than 100AH.

Q: Can it be used in air conditioners, water turbines and wind turbines?

A: It can be used in air conditioners, but not water turbines or wind turbines.

Q: Can is it a high frequency converter or a low frequency converter?

A: high frequency

Q: can the grid power be used to power the inverter when there is no sun?

A: yes.

Q: how to select the power of the inverter according to with household appliances connected?

A: if household appliances such as refrigerators, washing machines, air conditioners, etc. are connected, the inverter power must be at least three times the total power of the inductive receivers, otherwise the devices may not start.

Q: whether Can you use PV, battery, grid power at the same time?

A: yes. The default mode is PV priority. When the power from PV is insufficient, the battery and grid will be used.
