    10 pcs - VY1472M63Y5UQ63V0 Vishay Single Layer Ceramic Capacitor (SLCC) 4.7nF 500V ac ±20% Y5U Dielectric, VY1, Through Hole +12
    • 10 pcs - VY1472M63Y5UQ63V0 Vishay Single Layer Ceramic Capacitor (SLCC) 4.7nF 500V ac ±20% Y5U Dielectric, VY1, Through Hole +12

    10 pcs - VY1472M63Y5UQ63V0 Vishay Single Layer Ceramic Capacitor (SLCC) 4.7nF 500V ac ±20% Y5U Dielectric, VY1, Through Hole +12

    10(Allparts)8523393
    VISHAY
    10 pcs - VY1472M63Y5UQ63V0 Vishay Single Layer Ceramic Capacitor (SLCC) 4.7nF 500V ac ±20% Y5U Dielectric, VY1, Through Hole +125°C Max Op. Temp.
    £31.76
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Vishay VY1 SeriesVishay VY1 series capacitors have a ceramic disc of which both sides are silver-plated, encapsulated in a flame retardant epoxy resin. The radial connection leads are made of tinned copper clad steel. The VY1 capacitors offer a high reliability and extended temperature range making them suitable for a wide range of applications.FeaturesSinglelayer AC disc capacitorsFlame retardantHigh reliabilityCan pass 10 kV Pulses (10 per polarity)ApplicationsAcross-the-lineLine by-passAntenna couplingStandardsIEC 60384-14.4X7R Dielectric
    Product Details
    VISHAY
    10(Allparts)8523393
    VY1472M63Y5UQ63V0
    10 Items

    Data sheet

    Manufacturer
    VISHAY
    Capacitance
    4.7nF
    Tolerance
    ±20%
    Dimensions
    16 (Dia.) x 5mm
    Dielectric
    Y5U
    Diameter
    16mm
    Height
    5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    VY1
    Terminal Type
    Radial
    Maximum Operating Temperature
    +125°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -40°C
    Voltage
    500 V ac, 760V ac
    Dielectric Material Family
    Ceramic
