10 pcs - RY-5W-K Fujitsu Through Hole Signal Relay, 5V dc Coil, 1A Switching Current, DPDT
    • 10 pcs - RY-5W-K Fujitsu Through Hole Signal Relay, 5V dc Coil, 1A Switching Current, DPDT

    10 pcs - RY-5W-K Fujitsu Through Hole Signal Relay, 5V dc Coil, 1A Switching Current, DPDT

    10(Allparts)1958103
    FUJITSU
    Fujitsu Through Hole Signal Relay, 5V dc Coil, 1A Switching Current, DPDT
    £52.64
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Surge strength 1,500 VHigh dielectric strength type available (RY-WF type)Contact arrangement MBB type available (RY-D type)High reliability-bifurcated contactsWide operating rangeDIL terminalsPlastic sealed type
    Product Details
    FUJITSU
    10(Allparts)1958103
    RY-5W-K
    10 Items

    Data sheet

    Manufacturer
    FUJITSU
    Height
    12.5mm
    Application
    Signal
    Length
    20.2mm
    Contact material
    Gold Plated
    Depth
    9.8mm
    Number of poles
    2
    A-Supplier
    Allparts-UK/15/R-17
    Series
    RY
    Terminal Type
    Through Hole
    Maximum Operating Temperature
    +90°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -30°C
    Contact Configuration
    DPDT
    Switching Current
    1A
    Coil Resistance
    165Ω
    Maximum Switching Power AC
    60VA
    Coil Power
    150mW
    Isolation Coil To Contact
    1kV ac
    Maximum Switching Voltage AC
    120V ac
    Maximum Switching Power DC
    24 W
    Maximum Switching Current AC
    1 A
    Maximum Switching Current DC
    1 A
    Maximum Switching Voltage DC
    60V dc
    Coil Voltage
    5V dc
    Latching
    No
