Product Details
1AllpartsUK5951327ND
LP-24-100
3 Items
Data sheet
- Manufacturer
- Signal Transformer
- Part status
- Active
- Series
- LP
- Mounting Type
- Through Hole
- Type
- Semi-Toroidal
- Weight
- 0.313 lb (141.97 g)
- Termination Style
- PC Pin
- Packaging
- Bulk
- Size / Dimension
- 47.50mm L x 39.60mm W
- Height - Seated (Max)
- 16.50mm
- Power - Max
- 2VA
- Voltage - Isolation
- 1500Vrms
- Voltage - Primary
- 115V, 230V
- Voltage - Secondary (Full Load)
- Parallel 12V, Series 24V
- Current - Output (Max)
- Parallel 200mA, Series 100mA
- Primary Winding(s)
- Dual
- Secondary Winding(s)
- Dual
- Center Tap
- No
