    10 pcs : MQ172-3SA-CV(30) - Power to the Board PLUG 3P LOW PROFILE
    • 10 pcs : MQ172-3SA-CV(30) - Power to the Board PLUG 3P LOW PROFILE

    10 pcs : MQ172-3SA-CV(30) - Power to the Board PLUG 3P LOW PROFILE

    10(electronicparts)798MQ1723SACV30
    10 pcs : MQ172-3SA-CV(30) - Power to the Board PLUG 3P LOW PROFILE
    £55.11
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    MQ172 Micro-Miniature Interface Connectors Hirose Electric MQ172 Micro-Miniature Interface Connectors feature ultra-miniature/low profile SMT design. These interface connectors offer high current capacity with positive locking along with a wide variety of cables. The operating temperature of these connectors ranges from -30°C to 75°C. The MQ172 connectors SMT receptacles are packed in embossed tape and reel for automatic pick and place installation. The 2-point contact design and lead construction of these connectors help to resist vibration and shocks. Typical applications are portable remote terminals, portable telephones, notebook PCs, electronic measuring instruments and other similar applications.
    Product Details
    Hirose Connector
    10(electronicparts)798MQ1723SACV30
    MQ172-3SA-CV(30)
    10 Items

    Data sheet

    Manufacturer
    Hirose Electric
    Current rating
    3 A
    Contact material
    phosphor bronze
    Contact plating
    Gold
    Number of positions
    3 Position
    Series
    MQ
    Accessory Type
    -
    Voltage Rating
    40 VAC, 30 VDC
    Maximum Operating Temperature
    + 75 C
    Minimum Operating Temperature
    - 30 C
    Mounting Style
    Cable Mount / Free Hanging
    Housing Material
    Polyamide (PA)
    Housing Colour
    Black
    Product Type
    Power to the Board
    Number of Rows
    1 Row
    Contact Gender
    Socket (Female)
    Pitch
    0.8 mm
    Termination Style
    Crimp
    Product Category
    Power to the Board
    Packaging
    Tray
    RoHS
    Details
    Brand
    Hirose Connector
    Product
    Plugs
    Factory Pack Quantity Factory Pack Quantity
    50
    Subcategory
    Power Connectors
    Unit Weight
    200 mg
    Part # Aliases
    CL0206-0951-7-30 206-0951-7-30
    Wire Gauge Min
    32 AWG
    Wire Gauge Max
    24 AWG
    Mounting Angle
    Straight
    Wire Gauge Range
    32 AWG to 24 AWG
