    10 pcs - 2-1415899-3 TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPDT
    • 10 pcs - 2-1415899-3 TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPDT
    • 10 pcs - 2-1415899-3 TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPDT

    10 pcs - 2-1415899-3 TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPDT

    10(Allparts)7181721P
    TE Connectivity PCB Mount Power Relay, 24V dc Coil, 16A Switching Current, SPDT
    £52.38
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    TE Connectivity RZ Series PCB Power RelaysRZ Series PCB mounting power relays with a 400 mW DC coil and 5kV / 10mm reinforced insulation. These RZ Series PCB mounting power relays are flux tight and have silver nickel contacts.12A versions of these RZ Series PCB mounting power relays have 3.5mm pinning16A versions of these RZ Series PCB mounting power relays have 5 mm pinning3.2 or 5 mm pinningDimensions: 29.00 x 12.70 x 15.70 mmMeets the appliance industry requirements of IEC60335-1ApprovalsVDE and UL
    Product Details
    TE Connectivity
    10(Allparts)7181721P
    2-1415899-3
    10 Items

    Data sheet

    Manufacturer
    TE Connectivity
    Height
    15.7mm
    Application
    Power
    Length
    29mm
    Contact material
    silver alloy
    Depth
    12.7mm
    Number of poles
    1
    A-Supplier
    Allparts-UK/15/R-17
    Series
    RZ
    Terminal Type
    Through Hole
    Maximum Operating Temperature
    +85°C
    Mounting Type
    PCB Mount
    Minimum Operating Temperature
    -40°C
    Contact Configuration
    SPDT
    Switching Current
    16A
    Life
    10000000 (Mechanical) cycles, 30000 (Electrical) cycles
    Coil Resistance
    1440Ω
    Maximum Switching Power AC
    3 kVA
    Coil Power
    400mW
    Isolation Coil To Contact
    5kVrms
    Maximum Switching Voltage AC
    400V ac
    Coil Voltage
    24V dc
    Latching
    No
