    10 pcs - JV-9S-KT Fujitsu PCB Mount Power Relay, 9V dc Coil, 5A Switching Current, SPST
    • 10 pcs - JV-9S-KT Fujitsu PCB Mount Power Relay, 9V dc Coil, 5A Switching Current, SPST

    10 pcs - JV-9S-KT Fujitsu PCB Mount Power Relay, 9V dc Coil, 5A Switching Current, SPST

    10(Allparts)1958159
    FUJITSU
    Fujitsu PCB Mount Power Relay, 9V dc Coil, 5A Switching Current, SPST
    £51.19
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Low profile and space savingHeight: 12.5 mmMounting space: 175 mm2High sensitivity in small packageOperating power: 0.112 to 0.13 WNominal power: 0.2 to 0.3 WHigh insulation with reinforced insulation system (between coil and contacts)Insulation distance: 8 mmDielectric strength: 5,000 VACSurge strength: 10,000 VPlastic materials Plastic sealed type
    Product Details
    FUJITSU
    10(Allparts)1958159
    JV-9S-KT
    10 Items

    Data sheet

    Manufacturer
    FUJITSU
    Height
    12.8mm
    Length
    17.8mm
    Depth
    10.3mm
    Number of poles
    1
    A-Supplier
    Allparts-UK/15/R-17
    Series
    JV
    Terminal Type
    PCB Pin
    Mounting Type
    PCB Mount
    Contact Configuration
    SPST
    Switching Current
    5A
    Coil Resistance
    270Ω
    Maximum Switching Power AC
    1.25 kVA
    Coil Power
    300mW
    Isolation Coil To Contact
    10000 (Surge)V
    Maximum Switching Voltage AC
    250V ac
    Maximum Switching Power DC
    150 W
    Maximum Switching Current AC
    5 A
    Maximum Switching Current DC
    5 A
    Maximum Switching Voltage DC
    150V dc
    Coil Voltage
    9V dc
    Latching
    No
