1 pcs : MIKROE-5108 - Power Management IC Development Tools Monolithic Power Systems Inc.MP6523GR-Z
    • 1 pcs : MIKROE-5108 - Power Management IC Development Tools Monolithic Power Systems Inc.MP6523GR-Z

    1 pcs : MIKROE-5108 - Power Management IC Development Tools Monolithic Power Systems Inc.MP6523GR-Z

    Allparts-UK/M/932-MIKROE-5108
    MIKROE
    £43.64
    Delivery: 7-10 business days
    Quantity
    10 Items

    Description
    H-Bridge 10 Click Mikroe H-Bridge 10 Click features the Monolithic Power Systems (MPS) MP6523 triple, half-bridge, DMOS, output driver with integrated power MOSFETs. It can drive up to three different loads. The MP6523 is rated for an operating voltage range from 7V to 28V. It's SPI-configurable and has various diagnostic functions. Complete protection features include short-circuit protection (SCP), under-voltage protection (UVP), and thermal shutdown, alongside an onboard power supply existence-check circuit.
    Product Details
    MIKROE
    Allparts-UK/M/932-MIKROE-5108
    MIKROE-5108
    10 Items

    Data sheet

    Manufacturer
    MIKROE
    Dimensions
    42.9 mm x 25.4 mm
    Output voltage
    -
    Input voltage
    7 V to 28 V
    Maximum Operating Temperature
    + 120 C
    Minimum Operating Temperature
    - 40 C
    Type
    Brushed DC Motion Controller
    Output Current
    900 mA
    Product Type
    Power Management IC Development Tools
    Interface Type
    SPI
    Product Category
    Power Management IC Development Tools
    RoHS
    Details
    Brand
    Mikroe
    Product
    Add-On Boards
    Factory Pack Quantity Factory Pack Quantity
    1
    Subcategory
    Development Tools
    Tool Is For Evaluation Of
    MP6523
