Description
Higher Capacitance, Low ESR, High ripple currentLoad life of 2000 hours at 105°CSMD type : Lead free reflow soldering condition at 260°C peak correspondence
Product Details
Reference 20(Allparts)1872337P
MPN PCG0J222MCL1GS
In stock 10 Items
Data sheet
Manufacturer NICHICON Capacitance 2.2mF Tolerance ±20% Dimensions 10 x 12.7mm Leakage current 2.772 mA Diameter 10mm Height 12.7mm Length 10.3mm Depth 10.3mm A-Supplier Allparts-UK/15/R-11 Series CG Maximum Operating Temperature +105°C Mounting Type Surface Mount Minimum Operating Temperature -55°C Voltage 6.3V dc Technology Polymer Lifetime 2000h Equivalent Series Resistance 12mΩ Ripple Current 5A Polarised Polar Lead Pitch 4.6mm Electrolyte Type Solid Dissipation Factor 0.12%
