20 pcs - 870235374004 Wurth Elektronik 220μF Through Hole Polymer Capacitor, 16V dc
    • 20 pcs - 870235374004 Wurth Elektronik 220μF Through Hole Polymer Capacitor, 16V dc

    20 pcs - 870235374004 Wurth Elektronik 220μF Through Hole Polymer Capacitor, 16V dc

    20(electronicparts)8392231
    20 pcs - 870235374004 Wurth Elektronik 220μF Through Hole Polymer Capacitor, 16V dc
    £53.16
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Wurth Elektronik General Purpose WCAP-PT5H Capacitor Series 105°CAluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are: High permissible ripple current due to lower ESR at high frequency rangeHigher long term stability and expected lifeNo dry out phenomenon due to solid conductive polymerLow ESR at high frequency rangeOperating temperature: -55°C to +105°CLong life product series with 5000hLoad life of 5000h @ +105°CWave soldering is recommendedSolid Radial 105°C
    Product Details
    20(electronicparts)8392231
    870235374004
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Capacitance
    220µF
    Tolerance
    ±20%
    Dimensions
    8 (Dia) x 8mm
    Leakage current
    352 μA
    Diameter
    8mm
    Height
    8mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    WCAP-PT5H
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    16V dc
    Technology
    Polymer
    Lifetime
    5000h
    Equivalent Series Resistance
    10mΩ
    Ripple Current
    5.1A
    Lead Pitch
    3.5mm
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    8%
