50 pcs - APSG160ELL271MF08S CHEMI-CON 270μF Through Hole Polymer Capacitor, 16V dc
    • 50 pcs - APSG160ELL271MF08S CHEMI-CON 270μF Through Hole Polymer Capacitor, 16V dc

    50 pcs - APSG160ELL271MF08S CHEMI-CON 270μF Through Hole Polymer Capacitor, 16V dc

    50(electronicparts)1749909
    CHEMI-CON
    50 pcs - APSG160ELL271MF08S CHEMI-CON 270μF Through Hole Polymer Capacitor, 16V dc
    £66.38
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The Nippon Chem-Con Polymer Capacitor PSG Series offer super low ESR and high ripple current capability. The PSG Series Radial Conductive Polymer Aluminum Solid Capacitors from United Chemi-Con have an endurance of 2,000 to 5,000 hours at 105°C, rated voltage range of 16 to 20Vdc, operating temperature range of -55°C to 105°C, and capacitance range from 120μF to 1,000μF. PSG capacitors are RoHS compliant and halogen free.High capacitance model has been introduced to the product rangeappealing long life of 15,000/20,000 hours at 105°C Rated voltage 16V to 35V
    Product Details
    CHEMI-CON
    50(electronicparts)1749909
    APSG160ELL271MF08S
    10 Items

    Data sheet

    Manufacturer
    CHEMI-CON
    Capacitance
    270µF
    Tolerance
    ±20%
    Dimensions
    6.3 (Dia) x 8mm
    Leakage current
    500 μA
    Diameter
    6.3mm
    Height
    8mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    PSG
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    16V dc
    Technology
    Polymer
    Lifetime
    1000h
    Equivalent Series Resistance
    15mΩ
    Ripple Current
    3800mArms
    Polarised
    Polar
    Lead Pitch
    2.5mm
    Electrolyte Type
    Solid
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    12%
