50 pcs - A758KK687M0JAAE014 KEMET 680μF Through Hole Polymer Capacitor, 6.3V dc
    • 50 pcs - A758KK687M0JAAE014 KEMET 680μF Through Hole Polymer Capacitor, 6.3V dc

    50 pcs - A758KK687M0JAAE014 KEMET 680μF Through Hole Polymer Capacitor, 6.3V dc

    50(electronicparts)1739446
    KEMET
    50 pcs - A758KK687M0JAAE014 KEMET 680μF Through Hole Polymer Capacitor, 6.3V dc
    £64.83
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    KEMET’s A758 Single-Ended Conductive Polymer Aluminum Solid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A758 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents during normal operation. The A758 is ideally suited for industrial and commercial applications. Typical applications include mobile phone chargers, adapters (laptop power supplies) and medical equipment.Through-hole form factorMiniatureLow impedanceHigh ripple currentLong life105°C/5,000 hours
    Product Details
    KEMET
    50(electronicparts)1739446
    A758KK687M0JAAE014
    10 Items

    Data sheet

    Manufacturer
    KEMET
    Capacitance
    680µF
    Tolerance
    ±20%
    Dimensions
    8 (Dia) x 8mm
    Leakage current
    642.6 μA
    Diameter
    8mm
    Height
    8mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    A758
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    6.3V dc
    Technology
    Electrolytic
    Lifetime
    5000h
    Equivalent Series Resistance
    14mΩ
    Ripple Current
    4.1A
    Polarised
    Polar
    Lead Pitch
    3.5mm
    Electrolyte Type
    Solid
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    10%
