20 pcs - 870055674005 Wurth Elektronik 47μF Through Hole Polymer Capacitor, 35V dc
    • 20 pcs - 870055674005 Wurth Elektronik 47μF Through Hole Polymer Capacitor, 35V dc

    20 pcs - 870055674005 Wurth Elektronik 47μF Through Hole Polymer Capacitor, 35V dc

    20(electronicparts)8392326
    20 pcs - 870055674005 Wurth Elektronik 47μF Through Hole Polymer Capacitor, 35V dc
    £61.05
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Wurth Elektronik General Purpose WCAP-PTHR Capacitor Series 105°CAluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are: High permissible ripple current due to lower ESR at high frequency rangeHigher long term stability and expected lifeNo dry out phenomenon due to solid conductive polymerWCAP-PTHR is a high reliability polymer electrolytic capacitor seriesLow ESR at high frequency rangeHigh permissible ripple current Load life of 2000h @ +105°COperating temperature: -55°C to +105°CWave soldering is recommendedSolid Radial 105°C
    Product Details
    20(electronicparts)8392326
    870055674005
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Capacitance
    47µF
    Tolerance
    ±20%
    Dimensions
    8 (Dia) x 11.5mm
    Leakage current
    329 μA
    Diameter
    8mm
    Height
    11.5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    WCAP-PTHR
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    35V dc
    Technology
    Polymer
    Lifetime
    2000h
    Equivalent Series Resistance
    25mΩ
    Ripple Current
    2.89A
    Lead Pitch
    3.5mm
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    12%
