    20 pcs - 6SVPT330M Panasonic 330μF Surface Mount Polymer Capacitor, 6.3V dc
    • 20 pcs - 6SVPT330M Panasonic 330μF Surface Mount Polymer Capacitor, 6.3V dc

    20 pcs - 6SVPT330M Panasonic 330μF Surface Mount Polymer Capacitor, 6.3V dc

    20(electronicparts)2018083
    PANASONIC
    20 pcs - 6SVPT330M Panasonic 330μF Surface Mount Polymer Capacitor, 6.3V dc
    £52.12
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The Panasonic 330μF OS-CON SVP electrolytic aluminium capacitor construction with a high conductive polymer. It has excellent noise reduction capability and long life span. The capacitor used in PCs, motor drivers, measuring instruments, power supplies, security cameras and inverters.Low ESR is (15 mO max.)Large capacitance is (560 μF max.)Rated voltage range is 2.5 V to 16 V
    Product Details
    PANASONIC
    20(electronicparts)2018083
    6SVPT330M
    10 Items

    Data sheet

    Manufacturer
    PANASONIC
    Capacitance
    330µF
    Tolerance
    ±20%
    Dimensions
    6.3 x 6.6mm
    Leakage current
    415 μA
    Diameter
    6.3mm
    Height
    6.6mm
    Length
    6.4mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    SVPT
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Surface Mount
    Minimum Operating Temperature
    -55°C
    Voltage
    6.3V dc
    Technology
    Polymer
    Lifetime
    20000h
    Equivalent Series Resistance
    15mΩ
    Ripple Current
    3390mA
    Polarised
    Polar
    Lead Pitch
    2.1mm
    Electrolyte Type
    Solid
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    12%
