10 pcs - EEHZS1V331P Panasonic 330μF Through Hole Polymer Capacitor, 35V dc
    • 10 pcs - EEHZS1V331P Panasonic 330μF Through Hole Polymer Capacitor, 35V dc

    10 pcs - EEHZS1V331P Panasonic 330μF Through Hole Polymer Capacitor, 35V dc

    10(electronicparts)2105958
    PANASONIC
    10 pcs - EEHZS1V331P Panasonic 330μF Through Hole Polymer Capacitor, 35V dc
    £49.95
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    The Panasonic ZS series conductive polymer hybrid aluminium electrolytic capacitor has ±20 % tolerance and used 35 V voltage. It has 330μF of capacitance which size code is G12 and ultra low ESR between 13 mΩ and 19 mΩ.Endurance 4000 h at 125 ℃High ripple current and high capacitanceHigh-withstand voltage (to 63 V), low leakage current (0.01 CV or 3 μF)Vibration-proof product is available upon request.
    Product Details
    PANASONIC
    10(electronicparts)2105958
    EEHZS1V331P
    10 Items

    Data sheet

    Manufacturer
    PANASONIC
    Capacitance
    330µF
    Tolerance
    ±20%
    Dimensions
    10 x 12.5mm
    Leakage current
    115 μA
    Diameter
    10mm
    Length
    12.5mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    ZS
    Maximum Operating Temperature
    +125°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    35V dc
    Technology
    Hybrid
    Lifetime
    4000h
    Equivalent Series Resistance
    14mΩ
    Ripple Current
    3.5A
    Polarised
    Polar
    Dissipation Factor
    12%
