10 pcs - 870055675009 Wurth Elektronik 100μF Through Hole Polymer Capacitor, 35V dc
    • 10 pcs - 870055675009 Wurth Elektronik 100μF Through Hole Polymer Capacitor, 35V dc

    10 pcs - 870055675009 Wurth Elektronik 100μF Through Hole Polymer Capacitor, 35V dc

    10(electronicparts)8392341
    10 pcs - 870055675009 Wurth Elektronik 100μF Through Hole Polymer Capacitor, 35V dc
    £44.99
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Wurth Elektronik General Purpose WCAP-PTHR Capacitor Series 105°CAluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are: High permissible ripple current due to lower ESR at high frequency rangeHigher long term stability and expected lifeNo dry out phenomenon due to solid conductive polymerWCAP-PTHR is a high reliability polymer electrolytic capacitor seriesLow ESR at high frequency rangeHigh permissible ripple current Load life of 2000h @ +105°COperating temperature: -55°C to +105°CWave soldering is recommendedSolid Radial 105°C
    Product Details
    10(electronicparts)8392341
    870055675009
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Capacitance
    100µF
    Tolerance
    ±20%
    Dimensions
    10 (Dia) x 12.5mm
    Leakage current
    700 μA
    Diameter
    10mm
    Height
    12.5mm
    Length
    12.5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    WCAP-PTHR
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    35V dc
    Technology
    Polymer
    Lifetime
    2000h
    Equivalent Series Resistance
    25mΩ
    Ripple Current
    3.7A
    Polarised
    Polar
    Lead Pitch
    5mm
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    12%
