50 pcs - A750EK227M1AAAE018 KEMET 220μF Through Hole Polymer Capacitor, 10V dc
    • 50 pcs - A750EK227M1AAAE018 KEMET 220μF Through Hole Polymer Capacitor, 10V dc

    50 pcs - A750EK227M1AAAE018 KEMET 220μF Through Hole Polymer Capacitor, 10V dc

    50(electronicparts)1248262
    KEMET
    50 pcs - A750EK227M1AAAE018 KEMET 220μF Through Hole Polymer Capacitor, 10V dc
    £37.86
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    KEMET A750 SeriesThe KEMET A750 Series Surface Mount Conductive Polymer Aluminium Solid Electrolytic capacitors are designed for greater stability and longer life across a wide range of temperatures. The polymer capacitors are highly conductive generating less heat internally during operation. It includes low ESR properties, high ripple capability and open failure mode.FeaturesThrough-hole form factorUltra-low impedanceHigh-ripple current105°C/2,000 hoursApplicationsA750 Series are suitable for industrial and commercial applications:LED driver power suppliesLaptop power suppliesMobile phone chargersComputer motherboardsProfessional power amplifiersIndustrial control systems
    Product Details
    KEMET
    50(electronicparts)1248262
    A750EK227M1AAAE018
    10 Items

    Data sheet

    Manufacturer
    KEMET
    Capacitance
    220µF
    Tolerance
    ±20%
    Dimensions
    6.3 (Dia) x 8mm
    Leakage current
    440 μA
    Diameter
    6.3mm
    Height
    8mm
    Depth
    8mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    A750
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    10V dc
    Technology
    Polymer
    Lifetime
    2000h
    Equivalent Series Resistance
    18mΩ
    Ripple Current
    3.1A
    Polarised
    Polar
    Lead Pitch
    2.5mm
    Electrolyte Type
    Solid
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    12%
