50 pcs - A758BG106M1EAAE070 KEMET 10μF Through Hole Polymer Capacitor, 25V dc
    • 50 pcs - A758BG106M1EAAE070 KEMET 10μF Through Hole Polymer Capacitor, 25V dc

    50 pcs - A758BG106M1EAAE070 KEMET 10μF Through Hole Polymer Capacitor, 25V dc

    50(electronicparts)1739452
    KEMET
    50 pcs - A758BG106M1EAAE070 KEMET 10μF Through Hole Polymer Capacitor, 25V dc
    £37.84
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    KEMET’s A758 Single-Ended Conductive Polymer Aluminum Solid Electrolytic Capacitors offer longer life and greater stability across a wide range of temperatures. The A758 highly conductive solid polymer electrolyte eliminates the risk of explosion from drying out and due to its low ESR properties, is able to withstand higher ripple currents during normal operation. The A758 is ideally suited for industrial and commercial applications. Typical applications include mobile phone chargers, adapters (laptop power supplies) and medical equipment.Through-hole form factorMiniatureLow impedanceHigh ripple currentLong life105°C/5,000 hours
    Product Details
    KEMET
    50(electronicparts)1739452
    A758BG106M1EAAE070
    10 Items

    Data sheet

    Manufacturer
    KEMET
    Capacitance
    10µF
    Tolerance
    ±20%
    Dimensions
    5 (Dia) x 7mm
    Leakage current
    120 μA
    Diameter
    5mm
    Height
    7mm
    A-Supplier
    Allparts-UK/15/R-10
    Series
    A758
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    25V dc
    Technology
    Electrolytic
    Lifetime
    5000h
    Equivalent Series Resistance
    70mΩ
    Ripple Current
    750mA
    Polarised
    Polar
    Lead Pitch
    2mm
    Electrolyte Type
    Solid
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    10%
