20 pcs - 870135174006 Wurth Elektronik 1mF Through Hole Polymer Capacitor, 6.3V dc
    • 20 pcs - 870135174006 Wurth Elektronik 1mF Through Hole Polymer Capacitor, 6.3V dc

    20 pcs - 870135174006 Wurth Elektronik 1mF Through Hole Polymer Capacitor, 6.3V dc

    20(electronicparts)8392271
    20 pcs - 870135174006 Wurth Elektronik 1mF Through Hole Polymer Capacitor, 6.3V dc
    £29.58
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Wurth Elektronik General Purpose WCAP-PTHT Capacitor Series 125°CAluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are: High permissible ripple current due to lower ESR at high frequency rangeHigher long term stability and expected lifeNo dry out phenomenon due to solid conductive polymerWCAP-PTHT Series are high temperature polymer electrolytic capacitors Low ESR at high frequency rangeOperating temperature: -55°C to +125°CLoad life of 2000h @ +125°CWave soldering is recommended
    Product Details
    20(electronicparts)8392271
    870135174006
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Capacitance
    1mF
    Tolerance
    ±20%
    Dimensions
    8 (Dia) x 11.5mm
    Leakage current
    630 μA
    Diameter
    8mm
    Height
    11.5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    WCAP-PTHT
    Maximum Operating Temperature
    +125°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    6.3V dc
    Technology
    Polymer
    Lifetime
    2000h
    Equivalent Series Resistance
    9mΩ
    Ripple Current
    6.1A
    Lead Pitch
    3.5mm
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    10%
