10 pcs - 870235175007 Wurth Elektronik 1.2mF Through Hole Polymer Capacitor, 6.3V dc
    • 10 pcs - 870235175007 Wurth Elektronik 1.2mF Through Hole Polymer Capacitor, 6.3V dc

    10 pcs - 870235175007 Wurth Elektronik 1.2mF Through Hole Polymer Capacitor, 6.3V dc

    10(electronicparts)8392219
    10 pcs - 870235175007 Wurth Elektronik 1.2mF Through Hole Polymer Capacitor, 6.3V dc
    £26.64
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Wurth Elektronik General Purpose WCAP-PT5H Capacitor Series 105°CAluminium Polymer capacitors contain solid conductive polymer instead of wet electrolytic thus the benefits are: High permissible ripple current due to lower ESR at high frequency rangeHigher long term stability and expected lifeNo dry out phenomenon due to solid conductive polymerLow ESR at high frequency rangeOperating temperature: -55°C to +105°CLong life product series with 5000hLoad life of 5000h @ +105°CWave soldering is recommendedSolid Radial 105°C
    Product Details
    10(electronicparts)8392219
    870235175007
    10 Items

    Data sheet

    Manufacturer
    Wurth Elektronik
    Capacitance
    1.2mF
    Tolerance
    ±20%
    Dimensions
    10 (Dia) x 12.5mm
    Leakage current
    756 μA
    Diameter
    10mm
    Height
    12.5mm
    Length
    12.5mm
    A-Supplier
    Allparts-UK/15/R-11
    Series
    WCAP-PT5H
    Maximum Operating Temperature
    +105°C
    Mounting Type
    Through Hole
    Minimum Operating Temperature
    -55°C
    Voltage
    6.3V dc
    Technology
    Polymer
    Lifetime
    5000h
    Equivalent Series Resistance
    7mΩ
    Ripple Current
    6.64A
    Polarised
    Polar
    Lead Pitch
    5mm
    Dielectric Material Family
    Aluminium
    Dissipation Factor
    10%
