    20 pcs - 853-87-006-10-001101 Preci-Dip 853 Series Straight PCB Mount PCB Socket, 6-Contact, 2-Row, 1.27mm Pitch, Solder Termina
    • 20 pcs - 853-87-006-10-001101 Preci-Dip 853 Series Straight PCB Mount PCB Socket, 6-Contact, 2-Row, 1.27mm Pitch, Solder Termina

    20 pcs - 853-87-006-10-001101 Preci-Dip 853 Series Straight PCB Mount PCB Socket, 6-Contact, 2-Row, 1.27mm Pitch, Solder Termina

    20(Allparts)7023088
    Preci-Dip
    20 pcs - 853-87-006-10-001101 Preci-Dip 853 Series Straight PCB Mount PCB Socket, 6-Contact, 2-Row, 1.27mm Pitch, Solder Termination
    £56.07
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    1.27 mm IC Socket ConnectorsThese Swiss Preci-dip IC Ultraminiature PCB Socket Connector headers are solder tail Through Hole or SMD perpendicular Gull-Wing mount.Mating pin Ø 0.38 mm - 0,5 mmThe Through Hole headers have a Tail length of 2.3 mm for SIL and 2.4 mm for DILThe SMD mounting headers are perpendicular Gull-Wing typeSockets have Tin plated Brass sleeves with Flash Gold plated Beryllium Copper (4 finger) contact clipsStandardsUL 94V-0
    Product Details
    Preci-Dip
    20(Allparts)7023088
    853-87-006-10-001101
    10 Items

    Data sheet

    Manufacturer
    Preci-Dip
    Current rating
    12A
    Contact material
    beryllium copper
    A-Supplier
    Allparts-UK/15/R-10
    Series
    853
    Voltage Rating
    100 V , 150 V
    Mounting Type
    PCB Mount
    Type
    Board to Board
    Number of Contacts
    6
    Termination Method
    Solder
    Body Orientation
    Straight
    Number of Rows
    2
