Orlaco mast cable 20m 4p 0301831

PROFESSIONAL VISION SYSTEMSOrlaco specializes in the production of professional vision systems intended for forklifts, broadly defined heavy equipment, commercial vehicles, cranes, trucks, marine applications, emergency vehicles, railway applications, municipal vehicles and aviation vehicles. Around the world, Orlaco broadens the horizons of drivers, operators, captains and drivers, and thus increases the safety, efficiency and comfort of their work.

Orlaco has over 25 years of experience in designing and developing certified visual solutions that eliminate blind spots in vehicles, machines and ships . The company produces over 120,000 cameras, of which approximately 70 percent of products are delivered directly as factory equipment to the largest manufacturers of machines and devices from around the world.

Orlaco is a leading specialist in professional vision systems for OEMs around the world.

Object of the auction

=== ================================================================= =

Mast Cable 20.0 m 4P Molded(Orlaco dynamic multi-conductor 4-pin cable 20 m)

Orlaco multi-conductor 4-pin dynamic cable has a very versatile use in Orlaco vision systems wherever the cable is constantly susceptible to movement (constantly bent or coiled , etc.). Orlaco dynamic cables can work in all machines, vehicles and vessels. The product has EMC shielding, is resistant to oil and gasoline, is ADR compliant and has waterproof, molded connectors. Our offer also includes standard Orlaco cables - used in situations where the cable is not susceptible to movement (bent or coiled, etc. )

Orlaco multi-conductor 4-pin dynamic cables are available in various lengths.

Technical Specifications

=============================== =========================

Cable length: 20 m

Connectors: 4-pin connector

Core: Cable, item no. 1220600, coaxial, 7 x 0.10 mm SCWS, wires, 5 x AWG24 19 x 0.13 mm. TPC Color: black, red, orange, yellow, gray. Black housing, PUR.

Degree of protection: IP67 according to IEC 60529.

Approvals: UV-resistant, oil-resistant and halogen-free. Cables comply with UL Style 1589. Cable in accordance with UL Style 20963.

Fire resistance: VW1 (UL 1581).

Temperature range: -40 ° C ... + 85 ° C.

Intended use: The cable is intended for use on pulleys with a minimum diameter of 80 mm and a minimum width between the flanges of 10 mm.

The product card can be downloaded in the field: Additional Information

Photos of items and graphic symbols of the manufacturer were used for informational purposes and due to continuous improvement of products may, in some cases, differ slightly from those sent item.

Art-Trade distributor of ORLACO products in Poland.
