    50 pcs - RS PROSMD Non Resettable Fuse 0.5A, 600V
    • 50 pcs - RS PROSMD Non Resettable Fuse 0.5A, 600V

    50 pcs - RS PROSMD Non Resettable Fuse 0.5A, 600V

    50(Allparts)1824118
    RS PRO
    50 pcs - RS PROSMD Non Resettable Fuse 0.5A, 600V
    £47.47
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    RS PRO Surface Mount FuseThe RS PRO square ceramic non-resettable surface mount fuse has a voltage rating of 600V and current rating of 0.5A. It has a square cap of 3.10mm ± 0.20mm, a ceramic tube of 2.65mm ± 0.20mm, and an overall size of 10.10mm ± 0.40mm. It has a non-transparent ceramic tube body that does not allow breaking or deformation.Features and Benefits• Operating temperature ranging between -55°C and 125°C• Two gold-plated brass end caps for good conductivity• Maximum power dissipation: 0.4WApplications• Industrial steam jet• Fan control• Modem WAN interface cardCertifications• ANSI/ESD S20.20:2014• BS EN 61340-5-1:2007
    Product Details
    RS PRO
    50(Allparts)1824118
    10 Items

    Data sheet

    Manufacturer
    RS PRO
    Body material
    Ceramic Tube Non Transparent
    Current rating
    0.5A
    A-Supplier
    Allparts-UK/15/R-14
    Voltage Rating
    600V
    Maximum Operating Temperature
    +125°C
    Minimum Operating Temperature
    -55°C
    Body Length
    10.1mm
    Body Width
    3.1mm
    Breaking Capacity at Maximum Voltage Rating
    60 A @ 600 V ac
    Body Height
    3.1mm
