Hydraulic manual ball valve, 2-way 1 4

2-WAY HYDRAULIC BALL VALVE, TYPE 2/2, INTERNAL THREAD 1/4'Application: Widely used in hydraulic systems in agriculture, horticulture, forestry, construction and broadly understood industry.

Principle of operation:

'Close/open' valve used to block the oil flow on a single hydraulic line. The valve can be closed and opened even at high pressure.

Connection:

Connect A and P to the supply line where there is a need to open and close the flow.

Technical data:

Maximum flow: 25 l/min

Number of hydraulic holes in the body: 2

Internal threads in the body: [BSP] 1/4'

Body material: galvanized steel

Permissible maximum pressure: 500 bar

Weight: 0.500 kg

Temperature range and oil type:

Permissible ambient temperature: -40 C to +60 C

Permissible oil temperature: -15 C to +80 C

Oil type: Hydraulic oil based on mineral oil

Hydraulic diagram of the 2/2 ball valve (photo):

VALVE K 2D 1/4 BSP
