AL3022 Boost Controller Diodes Inc AL3022 boost controller is a constant 140KHz, voltage mode, external compensation boost controller. The AL3022 has low feedback voltage and makes it ideal for low cost LED backlight supplies. The AL3022 can support external PWM dimming and analog dimming. The AL3022 offers complete system protection with integrated Under Voltage Lockout, Over Voltage Protection, Over Current Protection, Output Voltage (VOUT) Short to GND Protection and Over Temperature Protection circuitry. To satisfy the limited PCB mounting space requirements, this IC is available in SO-8 package to save space.Learn More
