    30 pcs - B82731T2551A020 EPCOS 39 mH -30 - +50% Ferrite Power Line Choke, Max SRF:10kHz, 550mA Idc, 2.2Ω Rdc 250 V ac, B82731T
    • 30 pcs - B82731T2551A020 EPCOS 39 mH -30 - +50% Ferrite Power Line Choke, Max SRF:10kHz, 550mA Idc, 2.2Ω Rdc 250 V ac, B82731T

    30 pcs - B82731T2551A020 EPCOS 39 mH -30 - +50% Ferrite Power Line Choke, Max SRF:10kHz, 550mA Idc, 2.2Ω Rdc 250 V ac, B82731T

    30(Allparts)8711569
    EPCOS
    30 pcs - B82731T2551A020 EPCOS 39 mH -30 - +50% Ferrite Power Line Choke, Max SRF:10kHz, 550mA Idc, 2.2Ω Rdc 250 V ac, B82731T
    £63.53
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Epcos B82731T Series Power Line ChokesB82731T Series Current-compensated E Core double chokes, Closed E ferrite core with 4-section windingClosed PET coil former with 4 sections (UL 94 V-0) without encapsulationClearances ≥2.5 mm, creepage distances ≥ 3 mmHigh resonance frequency due to 2-section windingHigh pulse strengthLow whirring noiseApprox. 2% stray inductance for symmetrical interference suppressionSuitable for wave soldering
    Product Details
    EPCOS
    30(Allparts)8711569
    B82731T2551A020
    10 Items

    Data sheet

    Manufacturer
    EPCOS
    Tolerance
    -30 - +50%
    Dimensions
    21.5 x 13.5 x 21.1mm
    Height
    21.1mm
    Length
    21.5mm
    Depth
    13.5mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    B82731T
    Terminal Type
    PC Pin
    Maximum Operating Temperature
    +125°C
    Mounting Type
    Radial
    Minimum Operating Temperature
    -40°C
    Maximum DC Current
    550mA
    Inductance
    39 mH
    Lead Pitch
    10mm
    Lead Diameter
    0.64mm
    Maximum DC Resistance
    2.2Ω
    Core Material
    Ferrite
    Maximum Self Resonant Frequency
    10kHz
