    10 pcs - IHTH0750IZEB220M5A Vishay 22 μH ±20% Leaded Inductor, Max SRF:6.42MHz, 12.7A Idc, 13.2mΩ Rdc, IHTH-0750IZ-5A
    £52.64
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    IHTH0750 High Current Through Hole, High Temperature InductorsIHTH Series high current through hole, high temperature inductors for automotive applications. These inductors have a shielded construction and have excellent DC/DC energy storage up to 1MHZ. The IHTH inductors handle high translent current spikes without saturation, they also have an ultra low buzz noise, due to composite construction.The IHTH high current inductors come with 2 pins 0.47uH to 22uH and 3 pins 33uH to 100uH pins.ApplicationsDiesel injection driversEngine and transmission control unitsDC/DC Convertors for entertainment/ navigation systemsNoise suppression for motors - Windshield wipers - Power seats - Power mirrors - HID lighting - Heating and ventilation blowersLED driversStandardsAEC-Q200 qualifiedVishay Non Standard SMT Inductors (Chokes)
    Product Details
    VISHAY
    10(Allparts)1231528
    IHTH0750IZEB220M5A
    10 Items

    Data sheet

    Manufacturer
    VISHAY
    Tolerance
    ±20%
    Dimensions
    19.17 (Dia.) x 8.7mm
    Diameter
    19.17mm
    Height
    8.7mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    IHTH-0750IZ-5A
    Terminal Type
    Through Hole
    Maximum Operating Temperature
    +155°C
    Mounting Type
    Radial
    Minimum Operating Temperature
    -55°C
    Maximum DC Current
    12.7A
    Inductance
    22 μH
    Lead Pitch
    11.43mm
    Lead Diameter
    0.9mm
    Maximum DC Resistance
    13.2mΩ
    Maximum Self Resonant Frequency
    6.42MHz
