10 pcs - 1410517C Murata 1 mH ±10% Leaded Inductor, Max SRF:1.2MHz, Q:35, 1.7A Idc, 336mΩ Rdc, 1400
    • 10 pcs - 1410517C Murata 1 mH ±10% Leaded Inductor, Max SRF:1.2MHz, Q:35, 1.7A Idc, 336mΩ Rdc, 1400

    10 pcs - 1410517C Murata 1 mH ±10% Leaded Inductor, Max SRF:1.2MHz, Q:35, 1.7A Idc, 336mΩ Rdc, 1400

    10(Allparts)7156800
    10 pcs - 1410517C Murata 1 mH ±10% Leaded Inductor, Max SRF:1.2MHz, Q:35, 1.7A Idc, 336mΩ Rdc, 1400
    £52.12
    Delivery: 4-7 business days
    Quantity
    10 Items

    Description
    Murata 1400 Series High Current Radial InductorsDesigned for use in power line applications such as switching regulators, filters and suppression circuitsConstructed from high saturation flux density material enabling use in high current applicationsSuitable for PCB or chassis mounting using a non-magnetic fastener via the central fixing holeTerminated with easy-strip pre-tinned enamelled copper leadsLead length 10mmOperating temperature: -40 - +85°CInductance Tolerance: ±10%Murata Leaded Inductors (Chokes)
    Product Details
    10(Allparts)7156800
    1410517C
    10 Items

    Data sheet

    Manufacturer
    Murata Power Solutions
    Tolerance
    ±10%
    Dimensions
    27.2 x 25.9 x 20mm
    Height
    20mm
    Length
    27.2mm
    Depth
    25.9mm
    A-Supplier
    Allparts-UK/15/R-13
    Series
    1400
    Terminal Type
    Through Hole
    Maximum Operating Temperature
    +85°C
    Mounting Type
    Radial
    Minimum Operating Temperature
    -40°C
    Maximum DC Current
    1.7A
    Inductance
    1 mH
    Lead Pitch
    23.3mm
    Lead Diameter
    0.67mm
    Maximum DC Resistance
    336mΩ
    Maximum Self Resonant Frequency
    1.2MHz
    Minimum Quality Factor
    35
