Battery protection against discharge

Battery protection module against deep discharge

Operating voltage 12V- 36V (12V and 24V batteries)

Setting every 0.1V

Max. Load 20A

Consumption approx. 1W

settings memory after power failure

Display showing the current battery voltage

Dimensions length 57mm x width . 42mm x thickness 17mm

Settings:

Left key - when pressed, indicates the relay disconnection voltage. After holding it, you can set your voltage (default 10V)

Right key - sets the relay to be switched on again (hysteresis) After holding it, you can set your voltage (default 2V)

Example: Disconnection voltage 10V and hysteresis set to 2V. The system will disconnect the receiver at 10V and restart at 12V on the battery

Reset settings - hold both keys for 3s

Dimensions 57.2 mm x 42.1 mm
