Ab25 butyl mat, soundproofing, anti-vibration shaft

AB25 ANTI-VIBRATION BUTYL MAT WAWS Self-adhesive black aluminum butyl mat AB-25 by Bitmat AB-25 butyl mat by Bitmat Self-adhesive butyl mat made of aluminum

Most effective for soundproofing cars and machines

Thickness: 2.5 mm

Symbol: 25X50CM ABX25K

Raw material tested by PIMOT - Industrial Automotive Institute

The latest version of the AB-25 mat is on auction! The new AB-25 model has damping properties increased by 15% compared to the previous version.

The composition of the mixture and the density of the damping mass have changed. The aluminum layer (embossing) is also new, which is soft and easy to install. Thanks to this, it has increased resistance to cracks during installation.

Butyl rubber mat produced in Europe based on experience in the sale and installation of soundproofing materials from Standartplast - StP and Bitmat. After many years of tests and trials, we have achieved the most flexible and stretchable alubutyl mixture on the Polish market. As a manufacturer, we are constantly improving our products.

Alubutyl Bitmat is currently the best and most efficient material for soundproofing cars.

1 piece = 25 x 50cm2 pieces = 50 x 50cm

3 pieces = 75 x 50cm

4 pieces = 100 x 50cm

5 pieces = 125 x 50cm

6 pieces = 150 x 50cm

7 pieces = 175 x 50cm

8 pieces = 200 x 50 cm = 1m2

9 pieces = 225 x 50cm

10 pieces = 250 x 50cm

12 pieces = 300 x 50 cm = 1.5 m2

16 pieces = 400 x 50 cm = 2 m2

20 pieces = 500 x 50 cm = 2.5 m2

24 pieces = 600 x 50 cm = 3 m2

28 pieces = 700 x 50 cm = 3.5 m2 - a whole roll!

AB-25 soundproofing mat Made of pure butyl, 2.5 mm thick and low in weight, has increased density and ensures the highest damping parameters at such a low weight.

Adheres perfectly and arranges in hard-to-reach places such as embossed metal profiles on the floor, trunk or hood, but also fits perfectly on plastic door panels and is used in construction and industry.

The product is flexible and easy to install because it is made of natural materials - without waste fillers.

The product combines advantages of dense and flexible butyl rubber and the properties of real, cold-pressed aluminum.

This is the most effective model of butyl mats from the AB series from Bitmat that can be used in a car.

Properties: High-quality cold-bent aluminum 100µ-

Nanopolymer technology, high stability at low and low temperatures. high temperatures

UV resistance thanks to good quality aluminum

Does not contain asphalt masses, aromatic hydrocarbons and other harmful substances

High butyl density

AB-25 butyl mat from Bitmat Flexible and has optimal aluminum stiffness to eliminate vibrations.

Flame-retardant, which meets the standard ISO3795 (flammability of materials in road and agricultural vehicles)

The AB-25 butyl mat is the most effective model of butyl mats from the AB series from Bitmat that can be used in a car. Cars are minimally soundproofed by manufacturers, so you can significantly improve the comfort of traveling and well-being - using a butyl mat in your car.

(1) Below is a vibration reduction chart for our butyl mats: AB-1 (1.5mm - available on our other auctions), AB-2 (2mm - available on our other auctions) and AB-25 (2.5mm)

The curves show the vibration acceleration recorded on the measuring instrument. The shorter the vibration time, the fewer sound intensity units in dB.

Simply put, the fewer vibrations, the less noise!

(2) PIMOT research confirms the effectiveness of Bitmat materials from the AB series.

By sticking the mat on a selected element of the car, it dampens the vibrations of the sheet metal, which translates into a decrease in noise in the low frequency range, which is the most difficult to eliminate. Sound-deadening foams eliminate medium and high frequencies.

A properly soundproofed car provides excellent insulation of the cabin from outside sounds and, in addition, better sensations from the car audio system (stiffening the body elements affects the propagation of low tones inside the cabin - it creates a better sound pressure).

Below we present the readings Before and After soundproofing two cars.

The graphs show the difference in noise in Skoda Octavia (auto1) and Mazda 6 (auto2) before and after soundproofing.

The use of AB-2/25 butyl mat and Bitmat foams (available on our other auctions ) contributed to a decrease in the sound by up to a few decibels, thanks to which the noise was reduced by as much as 50%!

Advantages of AB-25 butyl mats from Bitmat: They do not require heating and have a strong adhesive

Resistant to water, oil and mold

No they crack and do not crumble

Very good thermal insulation thanks to thick aluminum

High flexibility results in an even better soundproofing effect

Effective reduction of rumbling, humming and vibration

They have an anti-corrosion effect - water often gets under cracked bituminous mats. We suggest removing falling bituminous mats

Approved for use in the automotive industry

Large mat surface - up to 7 m (700 x 50 cm) in one piece

They maintain maximum parameters in a wide temperature range from -45°C to +120°C!

They eliminate vibrations, humming and rumbling and create a noise barrier. They are much more effective than bituminous mats because rubber does not change its properties as much as bitumen (asphalt) during temperature changes.

Thanks to its high plasticity, the mat seals and thermally insulates through a thick 0.1 mm aluminum foil

Resistant to the effects of aging

Easily stretchable and molding while maintaining the highest damping parameters thanks to pure butyl mass. The price is comparable to bituminous mats, but the damping and comfort during gluing as well as the low weight definitely have an advantage over hard, thick and heavy bituminous mats

Safe for people and animals - no asphalt admixtures

Proven composition supported by research and over 12 years of experience

They are not toxic according to ROHS - tested by DEKRA (document below)

Differences between bituminous and butyl mats: do not require heating - bituminous mats must be heated with a heat gun

do not crack - bituminous mat is asphalt, which means it can crumble and crack

much greater flexibility results in even better quieting effect

they have an anti-corrosion effect - water often gets under cracked bitumen mats

larger mat surface - up to 7 m in one piece (700 x 50cm)

these are not roofing tapes and can only be used outdoors due to the solvents used

Application: 1. Passenger cars, trucks and special cars:* Roof

* Floor

* Wheel arches

* Hood

* Trunk lid

* Trunk

* Windshield

* Door panel

* Bulkhead

* Plastic engine cover

2. Machines and devices* Household appliances - washing machines, dishwashers, dryers, refrigerators

* Agricultural machinery - tractors, combines, lifts

* Aggregates

* Compressors

3. Private construction* Heat recovery units

* Central heating furnaces - Heating boilers

* Heat exchange pumps

How to soundproof a car? The best results can be achieved by using alubutyl in combination with rubber foams, creating a two-layer acoustic barrier against vibrations and noise. First, we apply the AB-25 butyl mat ( or other AB/StP - available on our other auctions) for each metal element, mapping it to the shape of the sheet metal

The second layer is a rubber waterproof foam - rubber foam (available on our other auctions)

Why several layers?

The butyl mat stiffens the body, creates a barrier to noise, eliminates resonance, rumbling and humming.

Rubber foam isolates against noise and high frequencies.

This combination creates the most effective soundproofing laminate! Sample number of butyl mats and rubber foams needed to soundproof a car*: Front pair of doors: 2 m2 of mats butyl and 1 m2 of 6 mm rubber foam**

Rear doors: 1.5 m2 of butyl and 1 m2 of 6 mm rubber foam**

Trunk with wheel arches: 3 m2 of butyl mat and 3 m2 of 9 mm rubber foam**

Floor with engine compartment: 3.5 m2 of butyl mat and 3.5 m2 of 9mm rubber foam**

Roof: 2 m2 of butyl mat and 2 m2 of 6mm rubber foam**

*Quantities may vary depending on the type/model of the car/vehicle

* *Foams available at our other auctions

***Approximate amounts of Bitmat butyl mat needed to soundproof a car (divided into segments) can be downloaded from the 'Additional information' tab

Installation advice▶️ Clean the soundproofing surface well with white spirit or remover

▶️ Cut the mat butyl mat to specific dimensions and stick it on the selected body element.

▶️ Roll out the butyl mat thoroughly with a roller - the roller is available on our other auctions

The butyl mat must be rolled out all the way and kneaded to the shape of the sheet metal.

Technical data:☑️ Name: AB-25

☑️ Thickness: 2.5 mm

☑️ Weight: 3.9 kg m2

☑️ Format: Roll

☑️ Width: 50 cm

☑️ Length: 25 cm

☑️ Butyl: Black

☑️ Aluminum: Flexible, black aluminum with white Bitmat print

☑️ Adhesive protective foil: Yes

☑️ Anti-corrosion properties: Yes

☑️ Asphalt admixture: None

☑️ Does not contain: Aromatic hydrocarbons and other harmful substances - composition tested by DEKRA

☑️ Use temperature: From -45°C to +120°C

☑️ Bond strength with metal at least: 15 MPa

☑️ Meets the standard: PN-ISO 3795

All photos come from assembly from our customers.

The price is for 1 piece of AB-25 butyl mat, dimensions: length 25cm x width 50cm, thickness - 2.5mm
