Pa6890 tip dn06 1 2 unf 90

PA6890 End cap DN06-1/2-UNF-90°EAN

8716106788187

Product details

Cone seal - metal on metal

Socket end

Cone angle

37 °

Shape

Elbow - 2 sides of connection

Connector type No. 1

Thread

Connector type no. 1 - male/female

Female

Connector type no. 1 - code

DKJ

C Length of connector no. 1

25.7 mm

F1 Connector thread diameter

1/2 inch< p>

Connector Thread Type

UNF

CH1 Wrench Size for Connector No. 1

17.0 mm

Connector No. Type 2

Hose connector

Connection type no. 2 - male/female

Male

Connection diameter no. 2

1/4 inch

Connection No. 2 Diameter

6 mm

D Connector No. 2 Length

30 mm

Angle

90 °

Material

Steel

Surface treatment

Galvanized

White passivated

OE reference number

H1222591-04050M

Connection

JIC union nut (UNF thread) with internal cone 74°

Application

Screw connections on the folded edge of the sheet metal

Type

DKJ
