Hose, hydraulic line 1sn dn10 180 bar

HYDRAULIC HOSE 1SN DN10 180 BAR

Application:

The original hose used in the production of hydraulic hoses, has a very wide range of applications in agriculture, industry and forestry. Designed for hydraulic systems with a maximum flow of up to 50 L/min and a pressure of up to 180 bar.

The hose is compatible with all fittings and sleeves from the DN10 group, which have the mark 1SN in their symbol.

Technical data:

Inner layer: synthetic rubber, with a smooth surface without joints and uniform thickness.

Outer layer: synthetic rubber resistant to oils, fuels and difficult weather conditions.

Inner reinforcing layer: double steel cross braid.

Operating temperature range of all layers: -40°C to 100°C

Recommended nominal operating pressure max. 180 bar.

Test pressure is twice the nominal pressure.

Burst pressure is four times the nominal pressure

Inner bore diameter: 10mm

Outer diameter: 19mm

The price is for 1 meter
