Oil flow divider valve 50 50 1 2 60l 80l

Oil flow divider valve 50:50 1/2' 3/8' 60l 80l 300bar V-EQ50 MIZAR number: 66311

Oil flow divider valve 50:50 1/2' 3/8' 60l 80l 300bar V-EQ50

It is widely used in hydraulic systems in agriculture, construction and industry.

The stream divider allows you to divide the working stream into two identical streams.

The stream is always divided equally, regardless of the change in flow (within the recommended range), pressure and load of individual receivers.

The divider can also combine two incoming streams into one main stream.

It is ideally used when two identical actuators, working independently, powered by one pump and controlled from one pump the distributor itself must work at an even pace.

In most cases, using a regular tee is not enough.

The valve also works well in systems where it is required to divide the main oil stream coming from the pump into two equal and independent streams that can be used to create two independent hydraulic systems.

In order for the divider to divide the oil evenly, it is recommended to maintain the oil flow within the range recommended by the manufacturer.

Technical information:

Recommended range of flow entering P: 60-80L/min

Number of hydraulic holes in the body: 3

Internal threads in the body:

P: 1/2'

A/B: 3/8'

Material: cast iron

PRESSURE RANGE:

Permissible maximum pressure: 300bar

TEMPERATURE RANGE AND OIL TYPE:

Permissible ambient temperature: -40 C to +60 C

Permissible oil temperature: -15 C to +80 C

Oil type: Hydraulic oil based on mineral oil

MIZAR number: 66311
