Set of external distributor valve 2 sections mf

External distributor kit, Massey Ferguson two-section valve MIZAR number: 72890

External distributor kit, Massey Ferguson two-section valve

* Special directional control valve for Massey Ferguson tractors.

* This valve is mounted directly on the lift cover instead of the main distributor.

* Intended for tractor models with a platform without a cabin, in which there is access to the hydraulic lift cover.

* Oil return from the valve directly to the hydraulic head of the lift.

* Only 4 hoses and fittings are needed for 2x double action

Lever description:

Lever 1: 3/8 working ports ' BSP.

Spring-loaded slider control, resulting in double acting. This lever is used to control the external hydraulics (tool/device connected to the tractor).

Lever 2: The connections are plugged, the slider control causes braking. This lever is used to switch between external and internal hydraulics.

Lever 3: 3/8' BSP working ports.

Spring-loaded spool control for double acting. This lever is used to control the external hydraulics (tool/device connected to the tractor).

Application: Perfect solution for operating log splitters, tipper trailers, etc.

Technical information:

Working connections: 3/8' BSP

2 x double acting control sections

Application:

Massey Ferguson

1004, 1004T, 1085,

122, 130, 133, 135, 135 US Built, 140, 145, 148, 150, 152, 155, 158, 165, 165 US Built, 168, 175, 175 US Built, 178, 178 US Built, 180, 185, 188,

20, 202, 204, 20C, 20D, 20E, 20F, 2135, 230, 230 US Built, 231, 235, 240 , 245, 250, 253, 255, 260, 261, 265, 270, 275, 282, 282 US Built, 283, 285 (FR), 285 US Built, 290, 290 US Built, 298,

30, 30B, 30D, 30E, 31, 3165, 340, 342, 35, 35 Gas / 35 Petrol, 35 US Built, 355, 35X, 360, 362, 365, 372, 375, 375E Brazilian, 383, 390, 390E Brazilian, 390T, 393, 396, 398, 399,

40, 40B, 40E,

50, 50C, 50D, 50E, 550, 560, 565, 590, 595 ,

65, 65 US Built, 670690, 675, 690, 698, 698T, 699,

TO35

MIZAR number: 72890
