Pf13890 tip dn13 1 2 bsp 90

PF13890 Tip DN13-1/2 BSP-90ºEAN

8716106786343

Cone angle

60 °

Shape

Elbow - 2 sides of connection

Connector type no. 1

Conical

Connector type no. 1 - male/female

Female

Type of connector no. 1 - code

DKOR

Length of connector no. 1

40 mm

Connector thread diameter< p>

1/2 inch

Connector Thread Type

BSP

Wrench Size for Connector No. 1

27.0 mm

Connector type no. 2

Hose connector

Connector type no. 2 - male/female

Male

Connection diameter no. 2

1/2 inch

Connection diameter no. 2

13 mm

ISO standard

228

Angle

90 °

Material

Steel

Surface treatment

Galvanized

White passivated

OE reference number

H1220893-080800

Connection

Union nut BSP with 60° external cone

Application

BSP screw connections

Type

DKOR
